NuPower Xtender™ SCISR-20 Tri-Band Bidirectional Amplifier

Part Number: NW-BA-SCISR-20-M02

Check out the newest SCISR model that replaces the SCISR-20

GSA Contract #: 47QSWA24D000V

The NuPower Xtender™ SCISR-20 Tri-Band Bidirectional Amplifier is a unique and versatile amplifier designed to support secure CDL ISR (SCISR) software-defined radio communications but can be used in any L-, S-, and/or C-band application.  The SCISR-20 simultaneously provides over 20 watts of RF transmit power, over 15 dB of receive gain, and features auto-sense T/R switching.

Description
Product Documents

Designed to Support:

The NuPower Xtender™ SCISR-20 Tri-Band Bidirectional Amplifier is a 20-watt amplifier† intended to simplify subsystem architecture with a compact form-factor offering in-band and cross-band bidirectional communication for improved link margin. Featuring auto-sense T/R capabilities with a 2-μs switching speed, the SCISR-20 automatically detects whether it is in transmit or receive mode in each channel, independent of the operational modes of the other channels.

This amplifier is designed to support secure CDL ISR (SCISR) software-defined radio communications as an easy-to-integrate addition to any ground or airborne terminal. While the SCISR-20 is designed to support these SCISR radios specifically, it can be used in any application requiring amplification in L-, S-, and C-band and can be customized for specific use-cases and unique requirements.

Small, compact, and rugged, the SCISR-20 is designed and built to last in the harshest of environments. Furthermore, NuWaves RF Solutions commitment to maintaining our AS9100D quality management system guarantees full materials traceability and quality accountability. Please contact us today for more information on how NuWaves’ SCISR-20 can take your system to the next level.

*Verified compatibility with radio OEM

†Band-dependent

Brochure
User Manual
3D Mechanical File
Block Diagram
Press Release
Export Classification
ECCN 5A991.B & 5991A.G
Operating Frequency
1000 to 5100 MHz
Max. Frequency
5100
Min. Frequency
1000
Output Power, Typ
20 W Psat
RF Gain, Typ
10
Input Drive
+30
VDC
27-32
Size
7.25 x 4.25 x 1.375
Weight
34.0
RF Connector Options
SMA
IF Input Freq Range
RF Output Freq Range
IF Bandwidth
IF Rejection, Typ
Frequency Range
Noise Figure, Typ
Tuning Resolution
Bandwidth, Typ
Transmit Frequency
Receive Frequency
Frequency Range
Central Frequency (MHz)
Passband Frequency (MHz)
Lower Stopband Frequency (MHz)
Lower Stopband Rejection (dBc)
Upper Stopband Frequency
Upper Stopband Rejection
Power Handling (W)
Insertion Loss
Size
7.25 x 4.25 x 1.375
Upper Stopband Frequency CH1
Center Frequency CH1
Lower Stopband Frequency CH1
Upper Stopband Frequency CH2
Center Frequency CH2
Lower Stopband Frequency CH2
Center Frequency
3 dB BW
20 dB BW
Insertion Loss
Export Classification
ECCN 5A991.B & 5991A.G
Frequency Range
Power Handling
Switch Time
