NuPower Xtender™ DUAL-S-50-C01-S01 Bidirectional Amplifier
The NuPower Xtender™ DUAL-S-50-C01-S01 is a 50W 2×2 dual channel bi-directional amplifier ideal for extending the range of communications and datalinks for ISR applications.
The NuPower Xtender™ DUAL-S-50-C01-S01 is a 50W 2×2 dual channel bi-directional amplifier ideal for extending the range of communications and datalinks for ISR applications. This amplifier supports NxN MIMO radios, where 2×2 or 4×4 configurations are used for high data rate applications. This amplifier combines a power amplifier, LNA, and switch, in an integrated microwave assembly for a low SWaP solution to pair with MIMO radios.
Based on highly linear LDMOS technology, this amplifier is perfect for applications requiring both high
data rates and high RF output power for long distance data links. It supports complex modulations with high peak-to-average ratios (PARs), where minimal signal distortion is required. Constant envelope
signals such as CW, AM, and FM are also supported.
At a nominal +30dBm (1Watt) RF input, the amplifier provides 17dB of gain to achieve a nominal 50
Watts at each of the antenna ports. Each channel is its own independent bi-directional amplifier. The
amplifier switches between transmit and receive through a DC control input. Alternatively, the module
can be configured for Autosense where it switches between transmit and receive automatically based
on the RF input power detected at the XCVR Port.
