NuPower™ S-10-C01-S01 Solid State Power Amplifier

Part Number: NW-PA-S-10-C01-S01

The NuPower™ S-10-C01-S01 is a small, highly efficient solid state power amplifier that provides 10 watts (typ) of RF power to boost performance of data links and transmitters.

Description
Product Documents

The NuPower™ S-10-C01-S01 is a small, highly efficient, S-Band, solid state power amplifier that provides 10 watts (typ) of RF power to boost performance of data links and transmitters.

Based on the latest gallium nitride (GaN) technology, NuPower’s 30% – 50% power efficiency and 3.25 in³ form factor make it ideal for size, weight, and power-constrained broadband RF telemetry and tactical communication systems. The NuPower S10S01 power amplifier accepts a nominal -5 dBm RF input and provides over 44 dB of gain from 3.0 GHz to 4.0 GHz. The NuPower S10S01 module has an optional NW-PA-ACC-CB09MA interface cable, for ease of integration. NuPower PAs feature over-voltage and reverse-voltage protection and can operate over a wide temperature range of -30 °C to +60 °C.

User Manual
Export Classification
EAR99
Operating Frequency
3000 to 4000 MHz
Max. Frequency
4000
Min. Frequency
3000
Output Power, Typ
10 Watts, Typ
RF Gain, Typ
44
Input Drive
-5
VDC
11-32
Size
3.25 x 2.0 x 0.5
Weight
3.0
RF Connector Options
SMA
IF Input Freq Range
RF Output Freq Range
IF Bandwidth
IF Rejection, Typ
Frequency Range
Noise Figure, Typ
Tuning Resolution
Bandwidth, Typ
Transmit Frequency
Receive Frequency
Frequency Range
Central Frequency (MHz)
Passband Frequency (MHz)
Lower Stopband Frequency (MHz)
Lower Stopband Rejection (dBc)
Upper Stopband Frequency
Upper Stopband Rejection
Power Handling (W)
Insertion Loss
Size
3.25 x 2.0 x 0.5
Upper Stopband Frequency CH1
Center Frequency CH1
Lower Stopband Frequency CH1
Upper Stopband Frequency CH2
Center Frequency CH2
Lower Stopband Frequency CH2
Center Frequency
3 dB BW
20 dB BW
Insertion Loss
Export Classification
EAR99
Frequency Range
Power Handling
Switch Time
