NuFilter™ 04BPCV-1538.5-SFSF-M01
Part Number: NW-FL-04BPCV-1538.5-SFSF-M01
The NuFilter™ 04BPCV-1538.5-SFSF-M01 provides superior harmonic and noise filtering, as demonstrated by the rejection levels of greater than 37 dB at 1450 and 1626 MHz. This high-performance module accepts input power levels up to 50 W, with only a minimal 1.5 dB of insertion loss in the passband frequency range of 1518 to 1559 MHz.
Size
1.85 x 1.42 x 0.45
Center Frequency (MHz)
1538.5
Lower Stopband Frequency (MHz)
1518
Lower Stopband Rejection (dBc)
-40
Upper Stopband Frequency (MHz)
1559
Upper Stopband Rejection (dBc)
-40
