ConvertaWave™ RF Downconverter

Part Number: RF225-500DCV1

The ConvertaWave™ model RF225-500DCV1, is a robust RF downconverter, providing high dynamic range performance over the 225-500 MHz frequency range.

Request a quote data sheet

The 70 MHz IF output is band-limited to 500 kHz. The downconverter provides superior rejection of out of band signals, Automatic Gain Control (AGC) / Manual Gain Control (MGC) operation, and operates over VHF and UHF frequencies in 100 kHz steps. The ConvertaWave has extremely low noise figure and user selectable features.

The ConvertaWave has over 100 dB of manual gain control, inclusive of an automatic gain control (AGC) mode. Boasting a system noise figure under 5 dB and a local oscillator (LO) with extremely low phase noise, the ConvertaWave is well suited for industrial, commercial, and military applications.

Demo units available to qualified customers.

Export Classification

ITAR Controlled

RF Output Freq Range

70 MHz

IF Input Freq Range

225 to 500 MHz

IF Bandwidth

500 kHz

IF Rejection, Typ

80 dB (typ)
