Cavity, Lumped Element, Stripline, and Microstrip Custom RF Filter Designs We make communication easy with everything you need and more than you expect

As a turn-key RF Microwave solutions provider, NuWaves offers RF & Microwave filter and multiplexer design services rivaling the industry’s major filter manufacturers, specializing in high-performance designs and industry-leading lead times. Our capabilities include:

  • PCB Stripline & Microstrip
  • High-Q Filters
  • Ultra-High Power Handling
  • Low Insertion Loss
  • Lightweight Designs
  • Tunable Frequency Designs
  • Low Manufacturing Costs
  • High Reliability
  • Multipaction Considerations
  • Tuning & Testing
  • Low SWaP Prof
  • Prototyping
  • Multiplexer Designs
  • High G-Force Applications
  • High Out-of-Band Attenuation
Frame 4nuwaves8
Frame 4nuwaves7

GPS III Tri-Band Multiplexer Design for Multipaction Performance

Our mechanical design team are experts in ruggedizing custom enclosures. Each design is customized to meet the environment in which the device will be operating in. Using innovative techniques NuWaves Engineering has designed ruggedized enclosures across the RF industry for government and commercial clients.

NuWaves’ unique tri-band multiplexer design successfully completed multipaction testing exceeding 800 Watts at each band, while achieving insertion loss of less than 0.5 dB for each band. This high performance tri-band multiplexer design serves the Air Force Research Lab’s (AFRL) Technologically Advanced N-plexer for GPS III Operation (TANGO), raising the bar for space qualified components by creating best-in-class multipaction performance.

High Performance Triplexer

NuWaves Engineering developed a triplexer for use by the Communications at Speed and Depth Program(s) for the Navy. The triplexer designed by NuWaves Engineering was Military UHF SATCOM Band Compliant and MUOS Band Compliant allowing for ease of integration for the customer. Additionally, the final product also achieved a lightweight design, low insertion loss, low manufacturing cost, support of high G-Force applications, high out-of-band attenuation, high RF power handling capability, and high reliability.

satcom_diplexer-300x225

Tri-Band Front End Multiplier

NuWaves’ X-Ceptor is a Broadband RF Downconverter/Tuner with high dynamic range performance covering VHF to S-Band. The X-Ceptor offers unmatched precision – 1 Hz tuning resolution – and superior rejection of out of band interference. The X-Ceptor operates across the military band in a myriad of applications for SATCOM receivers, COMINT, and SIGINT.

Miniature RF Front End Tuner Design

HiPerTuner-Image1-300x200

NuWaves’ HiperTUNER is a state-of-the-art miniature RF Tuner utilized for RF signals in the band of 200 MHz to 2.5 GHz. HiPerTUNER meets the demanding need for high performance receiver pre-selector and transmit filtering for applications involving RF communications and signal exploitation, inclusive of SIGNIT, COMINT, and ELINT. The HiPerTUNER integrates with a host controller or terminal program and utilizes a straight-forward command/control interface for ease of integration. The HiPerTUNER provides high-dynamic range performance with low noise figure and boasts superb multiple-cascaded varactor-tuned filtering achieving bandpass filter bandwidths of 1-3%.

Commercial Off-the-Shelf Filter Products and Quick-Turn, Custom Designs

Screenshot 2020-06-12 at 2.24.08 AM

NuWaves’ CNC Machine

In addition to providing high-performance filter and multiplexer design services, NuWaves also offers quick-turn custom filter design services for moderately complex filter designs, supported by NuWaves’ very own in-house Machine Shop.
Our quick-turn, custom RF & Microwave Filter products provide quotations within 24 hours that include a response plot and mechanical drawing, with lead times ranging from 2 – 3 weeks ARO. This program fulfills quick-turn designs for filters that are moderately complex in performance per the following parameters:

  • 1 to 20 GHz
  • 5% to 28% 3 dB bandwidth
  • Up to 50 W power handling

In need of a simple lumped element or SAW drop-in filter for an existing system? NuWaves also offers a line of Miniature, Connectorized Filters. Additionally, NuWaves offers Harmonic Filter solutions and a Quick-Turn Custom Cavity Filter service.

VIEW OUR COTS FILTERS
CONTACT US

High-Performance Solutions from Concept to Production
