NuFilter™ High Performance Custom RF Filters

The NuFilter™ product line includes quick-turn custom filters and complex custom filters. We design various filter topologies such as Bandpass, Highpass, Lowpass, and Notch filters.

Our QUICKFIL program provides quotations within 24 hours with a response plot and mechanical drawing. Receive your finished filter within 2 – 3 weeks after receipt of order. This program fulfills our quick-turn methodology of filters that are moderately complex in design and within the following parameters:

  • 1 to 20 GHz
  • 5% to 28% 3 dB bandwidth
  • Up to 50 W power handling

Are your specifications outside of these parameters? Not to worry, we cater to a full spectrum of RF filters.

Our CUSTOMFIL program provides the same expertise, but caters to more design-intensive, complex orders. The lead times reflect this complexity and can be longer than 3 weeks, typically less than 8 weeks.

Request A Custom Filter Quote Form
